Integrated LED light source
Luminaire designed for illumination of staircases, corridors, verandas, cellars, utility rooms, facades, etc. The modern LEDs used guarantee high energy efficiency and long service life. The impact-resistant diffuser is made of high-quality polycarbonate. The base is available in white. The luminaire additionally has a built-in PIR (infrared motion detector) and twilight sensor, so it only switches on the lighting when it is needed.
| General information: | |
|---|---|
| Outer diameter: | 330 mm |
| Nominal voltage: | 230 V |
| Lamp type: | LED, not replaceable |
| Suitable for lamp power: | 12 W |
| Rated luminous flux according to IEC 62722-2-1: | 1100 lm |
| With light source: | Yes |
| Colour temperature: | 3000 K |
| Max. power: | 12W |
| Rated life time L70/B50 at 25 °C: | 25000 h |
| Colour rendering index CRI: | >80 |
| Standby power: | 12 W |
| Material housing: | Plastic |
| Energy efficiency class of the built-in lamp: | F |
| Degree of protection (IP): | IP44 |
| Colour of light: | Warm |
| Power factor: | 1 |
| Flickering value Pst LM: | 0.1 |
| Stroboscope effect value SVM: | 0.1 |
| Impact strength: | IK10 |
| Protection class against electric shock: | II |
| Suitable for wall mounting: | Yes |
| Suitable for ceiling mounting: | Yes |
| Suitable for surface mounting: | Yes |
| Colour housing: | White |
| Material cover: | Matt / satin plastic |
| With movement sensor: | Yes |
| Type of sensor: | PIR |
| Detection range: | 3-6 m |
| Adjustable daylight sensor (LUX): | Yes |
| Daylight sensor adjustment range (LUX): | 10lux or 2000lux |
| Adjustable time setting (TIME): | Yes |
| Lighting time adjustment range (TIME): | 5 sek., 30 sek., 1 min., 3 min., 5 min., 8 min. |
| Adjustment of motion detection range (SENS): | Yes |
| Height/depth: | 110 mm |
